Steel structure table body to ensure durablity and precision.
Dual driving system on Y,track,pinion and gear system.
Electric limits on Y,machine stops at ends.Safe for machine and operator.
Separate driving system on X,track,pinion and gear system.
Electric limits on Y,machine stops at ends.Safe for machine and operator.
Automatic torch height controller on Z,You smile at a deformed plate.
Higher speed and higher precision.
Strong body to hold water bed table.
Caution light to reminder people safety and machine's safety.
Cable chain on X and on Y to protect cables.
Loading can be done by parts or by completely assembled machine
7"displayer,colorful interfaces,English,Russian,Spanish,Portuguese,French,Korean,Chinese.
44 shapes in controller library.
| Model | FLASHCUT |
| Power supply(V,Hz) | 1 phase, 110, 220, 230, 240, 50, or customised |
| Input capacity(KW) | 3 |
| Screen | 7”, colorful interface |
| Cutting width(mm) | 1500, 2000 |
| Cutting length(mm) | 3000, 4000, 5000, 6000 |
| Cutting model | Plasma(Flame to be optional) |
| CNC controller | Sparkon HG612 |
| Plasma | Powermax45 65 85 105 |
| Positioning speed(mm/min) | 12,000 |
| Recommended Positioning Speed(mm/min) | 6000-8000 |
| Accuracy(mm) | Positioning: 0.5/1000、Repeatability: 0.2/1000 |
| Machine size(mm) | 4500*2700*1600 |
| Optional 1 | Plate rider |
| Optional 2 | FastCAM, Turbonest, Pronest |
| Optional 3(mm) | Special for 1-3 |
