Portable MIG welder
Advanced IGBT inverter technology
Thermal protection
Stepless wire feeder and voltage seting
Handles a Wide Range of wire for a variety of welding materials
| Model | EXTREMIG 140 | EXTREMIG 160 | EXTREMIG 180 | EXTREMIG 182 |
| Input Power (V) | 120 | 230 | 230 | 120/230 |
| Rated Input Current (A) | 20 | 28.5 | 32 | 20/28 |
| Rated Input Capacity (kVA) | 2.4 | 6.55 | 7.36 | 2.4/6.4 |
| Rated Open Circuit Voltage(V) | 54 | 68 | 68 | 54 |
| Welding Current Adjustment Range(A) | 30-90 | 30-160 | 30-180 | 30-90/30-160 |
| Rated Output (A) | 100%/20%@90 | 40%/20%@160 | 40%/20%@180 | 40%/20%@160 |
| Weight (kg) | 12 | 12 | 12 | 12 |
| Wire Diameter (mm) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8/0.9 |
| LxWxH (mm) | 570x300x370 | 441x193x300 | 441x193x300 | 570x300x370 |
