Industrial on trolley plasma cutter
Thermal protection
Stepless current adjustment
Digital display
Smooth DC HF arc piloting
Handles a variety of metal materials
| Model | TRIDENT 40 | TRIDENT 60 | TRIDENT 100 | TRIDENT 120 | TRIDENT 160 | TRIDENT 200 |
| Input Power (V) | 400 | 400 | 400 | 400 | 400 | 400 |
| Rated Input Current (A) | 14 | 22.8 | 38 | 55 | 70.5 | 103 |
| Rated Input Capacity (kVA) | 9.8 | 15.8 | 26.3 | 38.2 | 48.8 | 71.4 |
| Output Open Circuit Voltage(V) | 220 | 230 | 280 | 305 | 330 | 340 |
| Current Regulation Range(A) | 40 | 60 | 70/100 | 85/120 | 95/160 | 120/200 |
| Rated Output (A) | 60%@40 | 60%@60 | 60%@100 | 60%@120 | 60%@160 | 60%@200 |
| Carbon Steel, Stainless Steel | 12/0.47 | 22/0.87 | 32/1.26 | 42/1.65 | 55/2.17 | 65/2.56 |
| Max Cutting Thickness (mm) | 12 | 22 | 32 | 42 | 55 | 65 |
| Brass Copper (mm/in) | 10 | 15 | 20 | 25 | 30 | 35 |
| Weight (kg) | 74 | 92 | 132 | 216 | 242 | 265 |
| LxWxH (mm) | 680x590x713 | 680x590x763 | 680x590x763 | 904x588x958 | 904x588x958 | 904x588x958 |
