The cart walks stability, use for welding wire 1.6-2.4mm
The machine has compacted structure and light weight .
The machine and lifting welding torch are slewed together and easy to adjust flexible rotation.
Adopt straightening institutions of the double drive wire feeders feed wire stably, wheel centering, huge traction, feed wire strongly
The cart can not only weld the straight seam of flat, but also can weld flat arc seam
| Main technical specification | MZ-ZK-A |
| Welding speed | 0.2-2.2m/min |
| Wire feeding speed | 0.4-6m/min |
| Welding current | 630A |
| Wire diameter | 1.6 2.0 2.4 |
| Wire type | solid core wire |
| Torch rotation angle | ±90° |
| Torch deflection angle | ±45° |
| Torch adjustable distance | 50x60 |
| Flux capacity | 2L |
| Wire spool capacity | 20KG |
| Dimensions ( LxWxH) | 750x350x740 |
| Weight | 53KG (not include wire ) |
