Easy transportation DC welder generator
Powerful and reliable engine
Thermal protection
Stepless welding current setting
Exceptional DC Stick welding performance
Ideal equipment for outdoor and field use
| Model | EDGE 150L | EDGE 170L | EDGE 190L |
| Function | CC/PIPE | CC/PIPE | CC/PIPE |
| Technology | DC/CC | DC/CC | DC/CC |
| Output Power (V/Hz) | 120/240V 50/60Hz | 120/240V 50/60Hz | 120/240V 50/60Hz |
| Phase | 1 | 1 | 1 |
| Output Power (W) | 1600/96 | 1600/96 | 1600/96 |
| Max Power (W) | 2000 | 2000 | 2000 |
| Rated input Current(A) | 16.7/8.3 | 16.7/8.3 | 16.7/8.3 |
| Fuel Tank (L) | 30 | 30 | 30 |
| Start Type | Manual | Manual | Manual |
| Rated Amperage(A) | 150 | 170 | 190 |
| Open Circuit Voltage (V) | 60-75 | 60-75 | 60-75 |
| Welding Current (A) | 60-150 | 60-170 | 60-190 |
| Duty Cycle (% at A) | 50% | 50% | 50% |
| Electrode/ Wire Dia (mm) | 1.6-3.2 | 1.6-4.0 | 1.6-4.0 |
| Machine Size (mm) | 700x540x570 | 700x540x570 | 700x540x570 |
| Package Size (mm) | 755x605x600 | 755x605x600 | 755x605x600 |
| NET Weight (kg) | 113 | 113 | 113 |
| Gross Weight (kg) | 121 | 121 | 121 |
